TEKNİK ÖZELLİKLER
Speaker type 2-way,
Bi-amp powered speaker, Bass-reflex type
Frequency range (-10dB) 50Hz – 20kHz
Nominal coverage (H) 90°
Nominal coverage (V) 60°
Components (LF) Diameter:15"
cone, Voice Coil:2.5", Magnet:Ferrite
Components (HF) Diaphragm:1.4",
Type: 1" throat compression driver, Magnet:Ferrite
Crossover 2.1kHz:
FIR-X tuning™ (linear phase FIR filter)
Output power Dynamic:1000
W (LF: 800 W, HF: 200 W) / Continuous: 465 W (LF: 400 W, HF: 65 W)
Maximum output level (1m; on axis) 132dB SPL
I/O connectors INPUT1:
Combo x1, INPUT2: Combo x 1 + RCA pin x 2 (Unbalanced), OUTPUT: XLR3-32 x 1
(CH1 Parallel Through or CH1+CH2 Mix)
Processors D-CONTOUR:
FOH/MAIN, MONITOR, OFF
Heat dissipation Fan
cooling, 4 speeds
Power requirements 100
V, 100-120V, 220-240 V, 110/127/220V (Brazil), 50/60Hz
Power consumption 74W(1/8
Power Consumption), 18W(Idle)
Cabinet material Plastic
Finish Black
Handle Side x 2
Flying and mounting hardware Bottom x 2, Rear x 1 (Fit for M8 x 15 mm eyebolts)
Pole socket 35mm
(Bottom x 1)
Dimensions 455mm
x 700mm x 378mm
Net weight 19.3
kg
