TEKNİK ÖZELLİKLER
System Type 15"
2-way, Bi-amp Powered Speaker, Bass-reflex Type
Frequency Range (-10dB) 45Hz ~ 20kHz
Frequency Response (-3dB) 55Hz ~ 18kHz
Coverage Angle H90°×V60°
Crossover Type FIR-X
tuning (linear phase FIR filter)
Crossover Frequency 1.7kHz
Maximum SPL (peak) IEC
noise @ 1m 136dB SPL
Amplifier
Amplifier Type Class-D
Power Rating 1300W
Low-Frequency 850W
High-Frequency 450W
Cooling Natural
Convection
HPF Frequency 120Hz
(-6dB) 24dB/oct
Boost Type D-CONTOUR
(Dynamic CONTOUR
Connectors Input XLR-3-31
x1 (Balanced) TRS Phone Jack x1 (Balanced)
Connectors Output XLR-3-32
x1 (Balanced) Parallel connection with INPUT
Connectors Power AC
inlet x1
Power Consumption 1/8Power
140W
Low-Frequency 15"
cone
Magnet Materials Neodymium
Magnet
Voice Coil Diameter 3"
High-Frequency 2"
Titanium diaphragm compression driver
Magnet Materials Neodymium
Magnet
Dimension (W x H x D) 370×638×368mm
(14 5/8"x25 2/8"x14 4/8")
Weight 28.0kg
