TEKNİK ÖZELLİKLER
Speaker type 8"
2-way, Bi-amp powered speaker, Bass-reflex type
Frequency range -10dB 57Hz
- 20kHz
Nominal coverage H 90°
Nominal coverage V 60°
Components LF Diameter:8"
cone, Voice Coil:2", Magnet:Ferrite
Components HF Diaphragm:1.4",
Type: 1" throat compression driver, Magnet:Ferrite
Crossover FIR-X
tuning™ (linear phase FIR filter)
Output power Dynamic:1100W
(LF: 950W HF: 150W) / Continuous: 700W (LF: 600W HF: 100W)
Maximum output level (1m; on axis) 129dB SPL
Processors D-CONTOUR
:FOH / MAIN, MONITOR, OFF
Power requirements 100V
- 240V, 50Hz/60Hz
Dimensions (W-H-D) W)
280mm(H)458mm(D)280mm
Net weight 13.5kg
Others Material:
ABS (Matte Finish, Black)
